Roxyne Mechanical Temperature Compensation Gas Meter is a membrane gas meter which adds a mechanical temperature compensation device, i.e. a spiral bimetal sheet, on the basis of a common membrane gas meter, and designs the track of the distorted crank shaft.As the ambient temperature changes relative to the standard state (20 C), the gas volume of the same mole number expands or shrinks.Membrane gas meters are bound to produce measurement deviations due to temperature changes.In order to accurately measure the comparable gas volume of the same mole number, the measurement bias caused by the change of temperature can be compensated by increasing or decreasing the gas meter's rotary volume.To achieve this compensation function, the length of the dislocated crank can be changed to increase or decrease the rotary volume of the gas meter by utilizing the displacement characteristic of the thermal bimetal sheet with the change of temperature. Finally, the same mole of gas measured is equal to the volume of gas in the standard state.Roxyne mechanical thermometer has accurate measurement, stable performance, anti-reversal device and prevents counting inversion.Suitable for measuring natural gas, artificial gas, liquefied petroleum gas and other media.
